| Specification | Detail |
|---|---|
| Switch Type | Unmanaged |
| Basic Switching RJ-45 Ethernet Ports Quantity | 8 |
| Basic Switching RJ-45 Ethernet Ports Type | 10G Ethernet (100/1000/10000) |
| Installed SFP Modules Quantity | 0 |
| Installed SFP+ Modules Quantity | 0 |
| 10G Ethernet (Copper) Ports Quantity | 8 |
| Networking Standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3p, IEEE 802.3x |
| Auto MDI/MDI-X | Yes |
| 10G Support | Yes |
| Auto-Negotiation | Yes |
| Jumbo Frames | 10000 |
| Packet Buffer Memory | 16 MB |
| MAC Address Table | 32000 entries |
| Switching Capacity | 160 Gbit/s |
| Store-and-Forward | Yes |
| Jumbo Frames Support | Yes |
| Forwarding Rate | 119 Mpps |
| Form Factor | 1U |
| Product Colour | Black |
| LED Indicators | Yes |
| Rack Mounting | Yes |
| Number of Fans | 1 fan(s) |
| Certification | CE, FCC, RoHS |
| Power Consumption (Max) | 28.4 W |
| Power Supply Included | Yes |
| AC Input Voltage | 100 - 240 V |
| AC Input Frequency | 50 - 60 Hz |
| Input Current | 0.8 A |
| Power Source | AC |
| Power over Ethernet (PoE) | No |
| Storage Temperature | -40 - 70 °C |
| Storage Relative Humidity | 5 - 90% |
| Operating Temperature | 0 - 50 °C |
| Operating Relative Humidity | 10 - 90% |
| Width | 11.6" (294 mm) |
| Depth | 7.09" (180 mm) |
| Height | 1.73" (44 mm) |
| Rack Mount Kit | Yes |
| Quick Start Guide | Yes |
| Cables Included | AC |
| Package Type | Box |
| Package Width | 9.84" (250 mm) |
| Package Depth | 15.7" (400 mm) |
| Package Height | 3.15" (80 mm) |
| Package Weight | 4.56 lbs (2.07 kg) |
| Harmonized System (HS) Code | 85176990 |
