| Specification | Detail |
|---|---|
| Switch Type | Managed |
| Web-Based Management | Yes |
| Quality of Service (QoS) Support | Yes |
| Switch Layer | L2 |
| Basic Switching RJ-45 Ethernet Ports | 18 |
| Basic Switching RJ-45 Ethernet Ports Type | Gigabit Ethernet (10/100/1000) |
| Combo SFP Ports | 2 |
| Gigabit Ethernet (Copper) Ports | 18 |
| Copper Ethernet Cabling Technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Cable Types Supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Networking Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| VLAN Support | Yes |
| Rate Limiting | Yes |
| Port Mirroring | Yes |
| Number of VLANs | 32 |
| Link Aggregation | Yes |
| Flow Control Support | Yes |
| Ethernet LAN Data Rates | 10, 100, 1000 Mbit/s |
| Broadcast Storm Control | Yes |
| Auto MDI/MDI-X | Yes |
| 10G Support | No |
| Auto-Negotiation | Yes |
| Virtual LAN Features | Port-based VLAN |
| IGMP Snooping | Yes |
| Fiber Ethernet Cabling Technology | 1000BASE-X |
| Jumbo Frames | 10000 |
| Packet Buffer Memory | 4.1 MB |
| MAC Address Table | 8000 entries |
| Switching Capacity | 36 Gbit/s |
| Store-and-Forward | Yes |
| Number of Queues | 4 |
| Jumbo Frames Support | Yes |
| Forwarding Rate | 26.78 Mpps |
| Loop Protection | Yes |
| Security Algorithms | SNMP, SNMPv2, SNMPv3 |
| Form Factor | 1U |
| Product Colour | Black |
| LED Indicators | Yes |
| Rack Mounting | Yes |
| Number of Fans | 2 fan(s) |
| Certification | CE, FCC, RoHS |
| Power Consumption (Max) | 296.3 W |
| Power Supply Included | Yes |
| AC Input Voltage | 100 - 240 V |
| Power Source | AC |
| Power over Ethernet (PoE+) Ports | 16 |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) Type Supported | PoE+ |
| Storage Temperature | -40 - 70 °C |
| Storage Relative Humidity | 5 - 90% |
| Operating Temperature | 0 - 50 °C |
| Operating Relative Humidity | 10 - 90% |
| Heat Dissipation | 741.15 BTU/h |
| Width | 440 mm (17.3") |
| Depth | 180 mm (7.09") |
| Height | 44 mm (1.73") |
| Rack Mount Kit | Yes |
| User Guide | Yes |
| Cables Included | AC |
| Harmonized System (HS) Code | 85176990 |
