| Specification | Detail |
|---|---|
| Traffic Classification | Yes |
| Switch Type | Unmanaged |
| Quality of Service (QoS) Support | Yes |
| Basic Switching RJ-45 Ethernet Ports | 18 |
| Basic Switching RJ-45 Ethernet Ports Type | Gigabit Ethernet (10/100/1000) |
| Installed SFP Modules | 0 |
| Installed SFP+ Modules | 0 |
| Combo SFP Ports | 2 |
| Gigabit Ethernet (Copper) Ports | 18 |
| Cable Types Supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
| MAC Address Auto-Learning Supported | Yes |
| MAC Address Auto-Aging Supported | Yes |
| Networking Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Full Duplex | Yes |
| Flow Control Support | Yes |
| Ethernet LAN Data Rates | 10, 100, 1000 Mbit/s |
| Auto MDI/MDI-X | Yes |
| 10G Support | No |
| Auto-Negotiation | Yes |
| Half Duplex | Yes |
| Jumbo Frames | 10000 |
| Packet Buffer Memory | 4.1 MB |
| MAC Address Table | 8000 entries |
| Switching Capacity | 36 Gbit/s |
| Jumbo Frames Support | Yes |
| Forwarding Rate | 26.78 Mpps |
| Form Factor | 1U |
| Product Colour | Black |
| LED Indicators | Yes |
| Housing Material | Metal |
| Rack Mounting | Yes |
| Number of Fans | 2 fan(s) |
| Certification | CE, FCC, RoHS |
| Power Consumption (Max) | 286.64 W |
| Power Supply Included | Yes |
| AC Input Voltage | 100 - 240 V |
| AC Input Frequency | 50 - 60 Hz |
| Power Source | AC |
| Power over Ethernet (PoE) Power per Port | 30 W |
| Power over Ethernet Plus (PoE+) Ports | 16 |
| Total Power over Ethernet (PoE) Budget | 250 W |
| Power over Ethernet (PoE) | Yes |
| Storage Temperature | -40 - 70 °C |
| Storage Relative Humidity | 5 - 90% |
| Operating Temperature | 0 - 50 °C |
| Operating Relative Humidity | 10 - 90% |
| Heat Dissipation | 977.44 BTU/h |
| Width | 440 mm (17.3") |
| Depth | 180 mm (7.09") |
| Height | 44 mm (1.73") |
| Quick Start Guide | Yes |
| Cables Included | AC |
| Package Width | 250 mm (9.84") |
| Package Depth | 528 mm (20.8") |
| Package Height | 80 mm (3.15") |
| Package Weight | 3.05 kg (6.72 lbs) |
| Harmonized System (HS) Code | 85176990 |
