| Specification | Detail |
|---|---|
| Switch Type | Managed |
| Quality of Service (QoS) Support | Yes |
| Switch Layer | L2 |
| Total Network Ports | 24 |
| Port Type | Gigabit Ethernet (10/100/1000) |
| Installed SFP Modules | 0 |
| Installed SFP+ Modules | 0 |
| Copper Ethernet Cabling | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Networking Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Full Duplex | Yes |
| Rate Limiting | Yes |
| Port Mirroring | Yes |
| Number of VLANs | 32 |
| Link Aggregation | Yes |
| Flow Control Support | Yes |
| Broadcast Storm Control | Yes |
| Auto MDI/MDI-X | Yes |
| 10G Support | No |
| IGMP Snooping | Yes |
| Jumbo Frames | 10000 |
| Throughput | 35.7 Mpps |
| Packet Buffer Memory | 4.1 MB |
| MAC Address Table | 8000 entries |
| Switching Capacity | 48 Gbit/s |
| Store-and-Forward | Yes |
| Number of Queues | 4 |
| Jumbo Frames Support | Yes |
| Product Colour | Black |
| LED Indicators | Yes |
| Rack Mounting | Yes |
| Certification | FCC, CE, RoHS |
| Power Supply Included | Yes |
| AC Input Voltage | 100 - 240 V |
| AC Input Frequency | 50 - 60 Hz |
| Power Consumption (Typical) | 14.19 W |
| Storage Temperature | -40 - 70 °C |
| Storage Relative Humidity | 5 - 90% |
| Operating Temperature | 0 - 40 °C |
| Operating Relative Humidity | 10 - 90% |
| Heat Dissipation | 48.39 BTU/h |
| Width | 294 mm (11.6") |
| Depth | 180 mm (7.09") |
| Height | 44 mm (1.73") |
| Rack Mount Kit | Yes |
| User Guide | Yes |
| Cables Included | AC |
| Package Type | Box |
| Harmonized System (HS) Code | 85176990 |
