TP-Link Omada SL2428P network switch Managed L2 Fast Ethernet (10/100) Power over Ethernet (PoE) 1U Black
Vendor:
TP-LINK
SKU:
SL2428P
- £146.05
-
- £146.05
- Unit price
- per
Subtotal:
£146.05
Couldn't load pickup availability
Delivery
Order by 4:30pm UK Time (excluding weekends and Bank Holidays) for UK Mainland next working day delivery. Shipping rates applicable only to UK Mainland Addresses and exclude Northern Ireland, Eire, Scottish Offshore, Scottish Highlands, Channel Islands and Isle of Man.
Standard £5.00 - 3 to 5 business days
Express £15.00 - 1 to 2 business days
Description
xTP-Link’s brand new Omada smart switches provide huge upgrade comparing with previous versions. The switches can be managed by Omada SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance.
Technical Specs
x| Specification | Detail |
|---|---|
| ARP Inspection | Yes |
| Switch Type | Managed |
| Web-Based Management | Yes |
| System Event Log | Yes |
| Quality of Service (QoS) Support | Yes |
| Multicast Support | Yes |
| Switch Layer | L2 |
| Configuring Location Settings (CLI) | Yes |
| Basic Switching RJ-45 Ethernet Ports | 24 |
| Basic Switching RJ-45 Ethernet Ports Type | Fast Ethernet (10/100) |
| Installed SFP Modules | 0 |
| Installed SFP+ Modules | 0 |
| Combo SFP Ports | 2 |
| Gigabit Ethernet (Copper) Ports | 4 |
| Fast Ethernet (Copper) Ports | 24 |
| Copper Ethernet Cabling Technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Cable Types Supported | Cat5, Cat5e |
| Networking Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| VLAN Support | Yes |
| Spanning Tree Protocol | Yes |
| Rate Limiting | Yes |
| Port Mirroring | Yes |
| Number of VLANs | 512 |
| Link Aggregation | Yes |
| Flow Control Support | Yes |
| Broadcast Storm Control | Yes |
| Auto MDI/MDI-X | Yes |
| 10G Support | No |
| IGMP Snooping | Yes |
| Jumbo Frames | 9000 |
| Throughput | 9.5 Mpps |
| Packet Buffer Memory | 4.1 MB |
| MAC Address Table | 8000 entries |
| Switching Capacity | 12.8 Gbit/s |
| Number of Queues | 4 |
| Jumbo Frames Support | Yes |
| SSH/SSL Support | Yes |
| Security Algorithms | SNMPv2, SNMPv3, SSH, SSH-2, SSL/TLS |
| Access Control List (ACL) | Yes |
| Management Protocols | SNMP v1/v2c/v3, RMON, SNTP, TFTP |
| Form Factor | 1U |
| Product Colour | Black |
| Rack Mounting | Yes |
| Number of Fans | 2 fan(s) |
| Certification | CE, FCC, RoHS |
| Firmware Upgradeable | Yes |
| Compatible Operating Systems | Microsoft Windows XP, Vista, Windows 7, Windows 8, MAC OS, NetWare, UNIX, Linux |
| Power Consumption (Max) | 291.6 W |
| AC Input Voltage | 100 - 240 V |
| AC Input Frequency | 50/60 Hz |
| Power Source | AC |
| Power over Ethernet (PoE+) Ports | 24 |
| Total Power over Ethernet (PoE) Budget | 250 W |
| Power over Ethernet (PoE) | Yes |
| Storage Temperature | -40 - 70 °C |
| Storage Relative Humidity | 5 - 90% |
| Operating Temperature | 0 - 40 °C |
| Operating Relative Humidity | 10 - 90% |
| Heat Dissipation | 995.09 BTU/h |
| Width | 440 mm (17.3") |
| Depth | 180 mm (7.09") |
| Height | 44 mm (1.73") |
| Rack Mount Kit | Yes |
| Quick Start Guide | Yes |
| Cables Included | AC |
