| Processor | |
|---|---|
| Processor cache type | L3 |
| Processor cache | 48 MB |
| Processor frequency | 2.2 GHz |
| Processor boost frequency | 4.1 GHz |
| Number of processors installed | 1 |
| Processor model | 6505P |
| Processor cores | 12 |
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® |
| Memory | |
| Internal memory | 64 GB |
| Memory layout (slots x size) | 2 x 32 GB |
| Memory slots | 32x DIMM |
| Memory clock speed | 6400 MHz |
| Maximum internal memory | 8 TB |
| Internal memory type | DDR5-SDRAM |
| Storage | |
| Supported RAID controllers | HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller |
| Number of SSDs supported | 8 |
| Total storage capacity | 960 GB |
| SSD interface | SATA III |
| SSD capacity | 480 GB |
| RAID support | Yes |
| Optical drive type | No |
| Number of SSDs installed | 2 |
| Supported SSD sizes | 2.5" |
| Storage drive type | 2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD |
| Graphics | |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Network | |
| LAN controller | Broadcom BCM57416 |
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Expansion slots | Maximum 3 PCIe Gen5 slots (x16 lanes/each) & Maximum 2 OCP3.0 slots (x16 lanes/each) |
| Number of management ports | 1 pc(s) |
| Optical drive | |
| Optical drive type | No |
| Design | |
| Rack mounting | Yes |
| Optical drive type | No |
| Chassis type | Rack (1U) |
| Cooling type | Active |
| Performance | |
| Security features | UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs. |
| Operating system installed | No |
| Management platform | Included - HPE iLO7 Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional - HPE iLO7 Advanced, and HPE OneView Advanced. Refer to the iLO 7 User Guide |
| Software | |
| Operating system installed | No |
| Power | |
| Number of main power supplies | 2 |
| Power supply type | 2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit |
| Redundant power supply (RPS) support | Yes |
| Power supply | 1000 W |
| Management features | |
| Management platform | Included - HPE iLO7 Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional - HPE iLO7 Advanced, and HPE OneView Advanced. Refer to the iLO 7 User Guide |
| Technical details | |
| Security features | UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs. |
| Rack mounting | Yes |
| Number of processors supported | 1 |
| Ethernet interface type | 10 Gigabit Ethernet |
| Chassis type | Rack (1U) |
| Standard fans | 5x Standard Fans |
| Weight & dimensions | |
| Width | 753.1 mm |
| Height | 42.9 mm |
| Depth | 434.6 mm |
| Other features | |
| Security features | UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs. |
| Number of processors supported | 1 |
| Standard fans | 5x Standard Fans |
| Storage drive type | 2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD |
